Stannol presents the Smart 4D Thermal Profiler: The new device enables precise analysis of temperature profiles in reflow soldering processes and supports companies in optimising their production quality.

Four-dimensional data acquisition

In modern soldering processes, precise temperature control is crucial in order to reliably achieve good solder joints and avoid failures. The Stannol Smart 4D Thermal Profiler measures and analyses the temperature curves directly on the assembly so that problems can be detected early and processes can be optimally adjusted. The device uses real 4D profiling to do this: it records the temperature (at the sensors), the system temperature (using pyrometers), the vibration measurement in XYZ (using acceleration sensors) and the time curve.

The key benefits include

• Fast and precise temperature measurement: directly on the assembly, for maximum process control
• Avoidance of soldering errors: through exact analysis and software-supported optimisation of the soldering profile
• Simple operation and intuitive software: with real-time data and clear analyses
• Improved system control: temperature and vibration measurement for early detection of technical problems
• Component-specific optimisation: fine-tuning of the soldering profile taking into account various component requirements
• Universally applicable: suitable for various oven types and soldering applications

The Stannol Smart 4D Thermal Profiler is now available and is aimed at electronics manufacturers who place high demands on temperature control and process stability. Further information is available at

https://www.stannol.de/en/smart-4d-thermal-profiler

About Stannol GmbH & Co. KG

Stannol can look back on a long tradition in solder production: the company has been combining experience and progress in its products for over 140 years. To this day, Stannol is regarded as a pioneer of modern soldering technology and is firmly established on the market as a brand. The company specialises in the production of solder wires, solder pastes, fluxes and bar solders. The product range also includes measuring and testing devices, cleaners, protective lacquers and other accessories. In addition to its high quality standards, Stannol is committed to sustainable and ecological production: Under the name greenconnect, the company offers a complete product range that focuses on sustainability and fairness. The greenconnect series has already won several awards.
